NVIDIA Ethernet MMA1Z00-NS400 Compatible QSFP112 400GBASE-SR4 PAM4 850nm 50m DOM MPO-12/APC MMF Optical Transceiver Module

NVIDIA Ethernet MMA1Z00-NS400 Compatible QSFP112 400GBASE-SR4 PAM4 850nm 50m DOM MPO-12/APC MMF Optical Transceiver Module

Compatible Brands

Product Highlights

  • Built-in Broadcom 7nm Chip, Max. Power Consumption 9W
  • Tested in Targeted Switches for Superior Performance, Quality, and Reliability
  • Compliant with QSFP112 MSA CMIS Rev4.0
  • Hot-pluggable QSFP112 Form Factor
  • High-speed Electrical Compliant to IEEE 802.3db



NVIDIA Ethernet MMA1Z00-NS400 Compatible QSFP112 400GBASE-SR4 PAM4 850nm 50m DOM MPO-12/APC MMF Optical Transceiver Module

The 400GBASE-SR4 module, MTP/MPO-12 connector, up to 50m over parallel OM4 multi-mode fiber. It is compliant with QSFP112 MSA, CMIS 4.0 Interface and 400GAUI-4 standards. The built-in digital diagnostics monitoring (DDM) allows access to real-time operating parameters. It is suitable for 400G ethernet and data center interconnect applications.

Specifications

NVIDIA Ethernet CompatibleMMA1Z00-NS400Vendor NameMvslink
Form FactorQSFP112Max Data Rate425Gbps (4×106.25Gb/s)
Wavelength850nmMax Cable Distance30m@OM3/50m@OM4
ConnectorMPO-12 (APC)MediaMMF
Transmitter TypeVCSELReceiver TypePIN
TX Power-4.6~4dBmMinimum Receiver Power-6.4dBm
Power Budget1.8dBReceiver Overload4.0dBm
Power Consumption≤9WExtinction Ratio>2.5dB
DDM/DOMSupportedCommercial Temperature Range0 to 70°C (32 to 158°F)
Modulation (Electrical)4x 106.25Gb/s PAM4Modulation (Optical)4x 106.25Gb/s PAM4
Packaging TechnologyCOBCore Size50μm
CDR (Clock and Data Recovery)TX & RX Built-in DSPInbuilt FECYes
ProtocolsIEEE Std 802.3db, QSFP112 MSA, CMIS 4.0Warranty3 Years

Quality Assurance

R&D team consists of experts with years of experience in the optical communications industry. Our manufacturers are top-class in the industry and support a product OEM. Installing a third-party transceiver does not affect your network equipment.

Quality Certifications

We follow the principle of quality first. We strictly control the quality of our products and comply with certification and safety standards. Currently,our products comply with industry standards and mainstream quality certifications, such as ISO 9001, CE, RoHS, FCC, UKCA, and so on.

Our advantages

Besides the price advantage we have compared to branded cables, MVSLINK InfiniBand Cables also maintain the same performance and reliability. To satisfy our customers` needs of high performance, all of our cables are tested multiple times in mainstream original brand switches in our test center before shipped out.

Advanced R&D Center

MVSLINK has an R&D center in Shanghai, focusing on analyzing customer and market needs and working with leading strategic R&D partners.

Quality Assurance

Each product has been tested for compatibility and interoperability on host devices, and has received many international certifications such as ISO, CE, and RoHS.

Customized Coding

All parts can be programmed to meet specific needs and unique codes can be created for customized network solutions.

Compatibility Guarantee

Oporteat vulputate id per. Nec in ignota iisque comprehensam. Ad impedit ceteros aliquando pro. Id mucius sanctus epicurei mea.

Compatibility Testing

MVSLINK utilizes Ethernet switches and network interface cards (NICs), ensuring each component is tested with certified equipment for optimal compatibility. Before shipment, optical modules are configured and tested on the corresponding Ethernet switches to guarantee that our products are 100% compatible with your network infrastructure.

Test
Test
Test

Questions & Answers

Q: Can an IB optical module be connected to an Ethernet optical module?
A: No, it is not possible. The optical modules on both ends need to be of the same type, either IB optical modules or Ethernet optical modules.
Q: If hypothetically we had a problem where we don’t know if the issue is with the modules or with the Mellanox switches, or maybe Mellanox switch failure due to the module’s problem, would you provide us technical support?
A: Of course. No matter what problem you have, you can just contact us directly. Mvslink will provide technical support: including switch and network configuration services to help you find out and solve problems.
Q: Why is the polished type of multimode patch cable used with NDR module MPO/APC (Angled Polished Connector)?
A: The 100G-PAM4 optoelectronic device is very sensitive to reflections occurring inside the fiber, about 10% of the light is reflected towards the transmitter when passing through the optical connector, distorting the data signal, and the APC’s optical connector deflects this reflected light.
Q: What is the difference between OSFP package and common packages such as QSFP28?
A: OSFP is longer and wider than the traditionally used QSFP28/EDR or QSFP56/HDR form-factors.
Q: Do you provide samples?
A: Yes,we can provide samples for test.You can tell us your needs then buy it from us.
